SDH2104U
HIGH VOLTAGE HALF BRIDGE DRIVER

    The SDH2104U is high voltage N-type power MOSFET and IGBT half bridge driver, whose built-in undervoltage lockout prevents the power device from working under low control voltage, and high/low side input interlock protection avoids the simultaneous conduction of both high side and low side MOSFETs.

Main feature

  • High-side floating supply absolute voltage:600V

  • Output current:+0.35A / -0.70A

  • 3.3V / 5V / 15V input logic compatible

  • Built-in dead time

  • Under-voltage (UV) lockout

  • dV/dt immune

Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SDH2104U SOP-8-225-1.27 SDH2104U Halogen free Tube
SDH2104UTR SOP-8-225-1.27 SDH2104U Halogen free Tape&Reel
Block Diagram


Documents
title Types of Size (KB) date Download the latest English version
SDH2104U PDF 232 2023-12-12 SDH2104U 簡要版說明書
